Product Name	Package	VDS(max)(V)	ID(max)(A)	PD(W)	VGS(max)(V)	RDS(on)(typ)(@10V) (mΩ)	RDS(on)(typ)(@4.5V)(mΩ)
	DFN22 PDFN3.3x3.3-8L-D PDFN5x6-8L-D SOT-363 SOT-23-6L SOP-8 TO-252-4L DFN34 SOP8	18/-18 20/-20 30/-30 40/-40 40/40 60/-60 100/-100 60 /-60	6/-6 25/-20 10/-7 20/-20 30/-30 1/-0.6 5/-5 4/-3 6.8/-5.8 9/-7 12/-12 10/-10 60/-60 34/-24 16/-16 8/-7 10/-9 11/-10 13/-12 4/-3.4 7.5/-4.5 27/-24 50/-44 60/-55 19/-16 50/-36 30/-22 34/-29 20/-14 25/-18 36/-22 15/-10 30/-19 16.5/-11 31/-15 12/-11 22/-17 27/-16 30/-21 7/-5 18/-16 15/-15 24/-18 7.5/-4.1 19/-14 6.5/-3.5 50/-50 12/-7 18/-18 35/-35 50/-48 30/-26 45/-40 55/-50 23/-23 17/-16 21/-20 25/-23 45/-45 36/-32 25/-24 8.9/-8.0 55 /-45 3/-3 5.8 /-6	18 2 25 2.1	±12 ±20 ±10	- 14/34 8.8/13.6 8.8/11.5 18/34 16/35 18/41 17/37 6.8/29 27/31 13/28 28/34 21/35 12/30 34/59 23/48 18/31 59/80 15/38.5 7.4/11.5 4.4/5.8 27/37.5 5.3/10.8 9.7/20.7 9.7/19.2 14.3/30.3 15.4/28 13.5/38 10/27 5.5/10.8 9.5/20.8 6.1/20.5 13/22 13/34 15.8/26 14.2/39 6.4/13 10/20 13.5/33 7/21.5 7.5/13 100/361 21/61 7.2/9 10/29.0 15/13 6.4/8.6 4.4/4.9 5.8/7.4 9.5/12 9.5/15 5.9/6.9 7.5/10.8 15/25 21 45 25 85	13/25 7.2/12 22/46 13/18.5 12.8/16.1 179/350 15/27 31/43 24/44 22/48 28/56 25/60 12/31 36/37 6.2/5.9 16/40 37/39 24/51 19/45 46/83 33/64 25/44 70/101 18.5/47 11.5/19.5 6.7/9.7 4.8/6.2 33/46.5 7.7/16.1 15/34.3 13.2/24.2 23.6/47 21/39.5 16.5/47 28/55 13.9/38 7.5/16.1 14.3/35 9.5/34 20/35 20/46 21.7/37 17.6/48 10.5/22.5 18/23 15/33 20.5/44 12/38 10/23 11/23 106/392 7.9/14.2 27/82 11/13.8 18/31 22/18 14/26 9.6/13.8 4.8/5.8 10/11.0 14.5/20.5 14.5/23.5 7.6/10 10.3/16.1 20/37 28 50 35 100

HNA18NP1325	DFN2*2	18/-18	6/-6	±12	-	13/25
HNM20NP0712A	PDFN3.3x3.3-8L-D	20/-20	25/-20	±12	-	7.2/12
HNM30NP2037A	PDFN3.3x3.3-8L-D	30/-30	10/-7	±20	14/34	22/46
HNS30NP0914	PDFN5x6-8L-D	30/-30	20/-20	±20	8.8/13.6	13/18.5
HNS30NP0812	PDFN5x6-8L-D	30/-30	30/-30	±20	8.8/11.5	12.8/16.1
HNW20NP200415K	SOT-363	20/-20	1/-0.6	±10	-	179/350
HNS18NP1527	SOT-23-6L	18/-18	5/-5	±12	-	15/27
HNS20NP3235	SOT-23-6L	20/-20	4/-3	±12	-	31/43
HNS30NP1834A	SOT-23-6L	30/-30	6.8/-5.8	±20	18/34	24/44
HNC30NP1627A	SOP-8	30/-30	9/-7	±20	16/35	22/48
HNC30NP1841LJ	SOP-8	30/-30	9/-7	±20	18/41	28/56
HNC30NP1737	SOP-8	30/-30	9/-7	±20	17/37	25/60
